VLD Series

• Self-resetting PPTC thermistor switch
• Design with nickel strips
• Hold current (at 25°C): 1,7 A to 2,1 A (depending on the model)
• Trip current (at 25°C): 3,4 A to 4,7 A (depending on the model)
• Operating voltage (max.): 16 V
• Short circuit current (max.): 100 A
• Maximum time to trip: 3,0 s at 8,5 A to 5,0 s at 10 A (depending on the model)
• Operating temperature range: -40°C to 85°C
• Total length (max.): 17,5 mm to 23,1 mm (depending on the model)
• Total width (max.): 7,4 mm to 5,3 mm (depending on the model)
• Approvals: TÜV, UL
